| Item | Parameters | |||||||
| Working environment | Indoor | Outdoor & Indoor | ||||||
| Model | HX-IRNDP2.6 | HX-IRNDP2.97 | HX-IRNDP3.91 | HX-RNDP2.6 | HX-RNDP2.97 | HX-RNDP3.91 | HX-RNDP4.81 | |
| Module | Lamp model | SMD1515 | SMD1515 | SMD2020 | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
| LED type | 3-in-1 SMD | |||||||
| Pixel configuration | RGB | |||||||
| Pixel pitch | 2.604mm | 2.97mm | 3.91mm | 2.604mm | 2.97mm | 3.91mm | 4.81mm | |
| Physical density (dot/m2) | 147456 | 112896 | 65536 | 147456 | 112896 | 65536 | 43264 | |
| Cabinet | Resolution | 192X192 | 168X168 | 128X128 | 192X192 | 168X168 | 128X128 | 104X104 |
| Size (HxV) | 500X500X82mm | |||||||
| Weight (KG) | 7.2 | 7.2 | 7.2 | 7.3 | 7.3 | 7.3 | 7.3 | |
| Serviceability | Front /Rear service | |||||||
| Material | Die casting aluminum | |||||||
| Display | IP rating(front/rear) | IP40/IP43 | IP65/43 | |||||
| White balance brightness (nits) | ≥600 | ≥600 | ≥600 | 4000-4500 | 4000-4500 | 4000-4500 | 4000-4500 | |
| Color temperature（K） | 3200—12000 adjustable | |||||||
| Hor. viewing angle(min 50% brightness) | 140° | 140° | 140° | 140° | 140° | 140° | 140° | |
| Vert. viewing angle(min 50% brightness) | 140° | 140° | 140° | 120° | 120° | 120° | 120° | |
| Contrast ratio | 8000：1 | 8000：1 | 6000：1 | 6000：1 | 6000：1 | 6000：1 | 6000：1 | |
| Max. power Consumption（W/m2） | ≤640 | ≤640 | ≤640 | ≤680 | ≤680 | ≤680 | ≤680 | |
| Avg. power Consumption（W/m2） | ≤192 | ≤192 | ≤192 | ≤200 | ≤200 | ≤200 | ≤200 | |
| Operation power voltage | AC100-240V | |||||||
| Frame frequency （Hz） | 50/60 | |||||||
| Colors | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion | 281 trillion | |
| Refresh rate(HZ) | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 | |
| Processing | 16bit/color | 16bit/color | 16bit/color | 16bit/color | 16bit/color | 16bit/color | 16bit/color | |
| Operating temperature range | -20°C to +50°C | -20°C to +50°C | -20°C to +50°C | -20°C to +50°C | -20°C to +50°C | -20°C to +50°C | -20°C to +50°C | |
| Storage temperature range | -25°C to +80°C | -25°C to +80°C | -25°C to +80°C | -25°C to +80°C | -25°C to +80°C | -25°C to +80°C | -25°C to +80°C | |
| Operating humidity | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% | |
| Storage humidity | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% | |
| Life time(50% brightness) | 100,000 hours | |||||||
