| Item | Parameters | |||
| Working environment | Indoor | |||
| Model | HX-IFWP1.86 | HX-IFWP2 | HX-IFWP2.5 | |
| Module | Lamp model | SMD1515 | SMD1515 | SMD1515 |
| LED type | 3-in-1 SMD | |||
| Pixel configuration | RGB | |||
| Pixel pitch | 1.86mm | 2.0mm | 2.5mm | |
| Physical density (dot/m2) | 288888 | 250000 | 160000 | |
| Cabinet | Resolution | 344X258 | 320X240 | 256X192 |
| Size (HxVXD) | 640X480X47.6mm | |||
| Estimated weight (KG) | 5 | 5 | 5 | |
| Serviceability | Front service, front installation | |||
| Material | Die casting aluminum | |||
| Display | IP rating(front/rear) | IP40/IP43 | ||
| White balance brightness (nits) | 600-800 | 600-800 | 600-800 | |
| Color temperature（K） | 3200—12000 adjustable | |||
| Hor. viewing angle(min 50% brightness) | ≥140° | ≥140° | ≥140° | |
| Vert. viewing angle(min 50% brightness) | ≥120° | ≥120° | ≥120° | |
| Contrast ratio | ≥5000：1 | ≥5000：1 | ≥5000：1 | |
| Max. power Consumption（W/m2） | ≤600 | ≤600 | ≤600 | |
| Avg. power Consumption（W/m2） | ≤180 | ≤180 | ≤180 | |
| Operation power voltage | AC110V/220V +/- 10% | |||
| Frame frequency （Hz） | 50&60 | |||
| Colors | 281 trillion | 281 trillion | 281 trillion | |
| Refresh rate(HZ) | ≥3840 | ≥3840 | ≥1920 | |
| Processing | 16bit/color | 16bit/color | 16bit/color | |
| Operating temperature range | -20°C to +50°C | -20°C to +50°C | -20°C to +50°C | |
| Storage temperature range | -25°C to +80°C | -25°C to +80°C | -25°C to +80°C | |
| Operating humidity | 10%~90% | 10%~90% | 10%~90% | |
| Storage humidity | 10%~90% | 10%~90% | 10%~90% | |
| Life time(50% brightness) | 100,000 hours | |||
We’ve been using HXTECH’s waterproof LED displays for over a year now across our highway billboards. Rain, wind, even snow—these screens never fail. Excellent brightness and very reliable.
The HXTECH outdoor LED screens held up perfectly during our rainy summer music festivals. The visuals stayed sharp and vivid throughout. Setup and teardown were also surprisingly fast.
